Kunzmann Milling Machine WF 7/3 F6
Kunzmann WF 7/3 F6 milling machine with SK40 tooling, 800 x 425 mm table, 600 x 400 x 400 mm travel, and a control cabinet.
Workshop EquipmentAvailable
6.500,00 €
Esasy maglumatlar
- Onduriji
- Kunzmann
- Yagday
- Good
- Kategoriya
- Workshop Equipment
Düsündiris
Kunzmann WF 7/3 F6 milling machine. Key specifications include a working table of 800 x 425 mm with a maximum load of 250 kg. Axis travels are X 600 mm, Y 400 mm, Z 400 mm. From the table top to spindle center is 130–550 mm, and from the table top to the bottom edge of the vertical head is up to 480 mm. Tooling is SK40. Spindle speeds are 60–3700 rpm in both horizontal and vertical directions. Quill stroke (vertical) is 60 mm. The vertical head swivels ±90°. Feeds (along and cross) 0–4000 mm/min with rapid traverse 5000 mm/min; vertical feed 0–4000 mm/min with vertical rapid 4000 mm/min. The machine includes a control cabinet and a swiveling console. Weight is about 2000 kg with overall dimensions of 2.00 x 2.00 x 2.00 m. Serial number: 370216. The hour counter cannot be read due to the age. A handwheel is present. The protective screen has a crack (see image). No operating manual is included. EC conformity declaration is present. The milling machine was decommissioned on 31 July 2026 at 10:00. The machine can be loaded on level ground.
